PA-9100D
PA-9100D
343 116 Ft
  1. Keverőerősítők
  1. MONACOR
  2. PA Technológia
  3. Erősítők
  4. Keverőerősítők

PA-9100D

Cikkszám:
PA-9100D
PA-9100D
PA-9100D
PA-9100D
PA-9100D
PA-9100D
PA-9100D
Rendelhető
343 116 Ft
Terméknév:
D-osztályú PA erősítő

Kérdés esetén keressen bizalommal!

audioseed.hu

Gyenge András

+36 30 553 6946

Üzenetet írok!

Mono class D PA mixing amplifier, 1,000 W
Kiegészítő termékek
  • Részletek
  • Adatok
  • Vélemények
  • Letöltések
Részletek


Mono class D PA mixing amplifier

  • 1 x 1,000 W
  • Class D concept with PASCAL amplifier module
  • Energy-efficient concept due to high efficiency
  • Lightweight design due to compact switch-mode power supply
  • Silent operation due to fanless cooling concept
  • 4 balanced mic/line inputs
  • Mic 1 with priority circuit and automatic talkover
  • Additional connection for desktop microphone via screw terminal
  • 1 aux input
  • Speaker outputs via screw contacts
  • Line output
  • Insert facility, e.g. for effect units, equalizers, feedback controllers
  • Input level control and output level control
  • 2-way tone control for the output
  • 48 V phantom power supply for each microphone input, to be activated individually
  • Limiter switch 4 Ω/8 Ω/100 V
  • Removable mounting brackets



Manufacturer information:

MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com



Safety Notes and Warning Messages

The unit uses dangerous mains voltage. Leave servicing to skilled personnel only and do not insert anything into the air vents. Inexpert handling may result in electric shock.
During operation, there may be a hazard of contact with a dangerous voltage of up to 100 V at the speaker terminals. Always switch off the amplifier before making or changing any connections.
Do not operate the unit and disconnect the mains plug from the socket immediately if the unit or the mains cable is visibly damaged; if a defect might have occurred after the unit was dropped or suffered a similar accident, if malfunctions occur. In any case, the unit must be repaired by skilled personnel.
The unit is suitable for indoor use only. Protect it against dripping water and splash water, high air humidity and heat (admissible ambient temperature range: 0 - 40 °C).
Never pull the mains cable to disconnect the mains plug from the socket, always seize the plug.
The heat generated inside the unit must be dissipated by air circulation; never cover the air vents of the housing.
If the unit is to be put out of operation permanently, take it to a local recycling plant for a disposal which is not harmful to the environment.


Adatok
Ventillátor nélküli:
1
Mains frequency:
50-60 Hz
Kisimpedanciás:
1
Magasság:
88 mm
Jel/zaj-viszony:
> 80 dB
Átviteli tartomány:
20-20.000 Hz
Connections:
4 x XLR (mic/line),

1 x RCA L/R (aux),

screw contacts (speakers)

Névleges teljesítmény:
1.000 W
Névleges teljesítmény 4Ω-on:
900 W
Névleges teljesítmény 8Ω-on:
1.000 W
Tömeg:
5,6 kg
Bruttó súly:
6,6 kg
Max. teljesítmény:
1.000 W
100 V:
1
Megengedett körny. hőm.:
0-40 °C
Inputs:
3 mV (mic),

200 mV (line),

140 mV (aux)

Üzemi áramfelvétel:
1.030 VA
Tápellátás:
- 90-230 V
Fantomtáp:
48 V
Nettó súly:
5,6 kg
Limiter:
igen
Csatornák:
5
Szélesség:
482 mm
Packing dimensions (W x H x L):
0.5 x 0.13 x 0.36 m
Mélység:
275 mm
Rack units, RU:
2
Teljes harmonikus torzítás:
< 0,1 %
Equalizer bass:
± 10 dB/100 Hz
Power supply:
˜ 90-230 V/50-60 Hz/1,100 VA
Power rating at 100 V:
1,000 W@9.2 Ω
Kimeneti impedancia:
4-8 Ω
Equalizer treble:
± 10 dB/10 kHz
Packaging dimensions (W x H x L):
0.5 x 0.13 x 0.36 m
EAN code:
4,007,754,275,827
Vélemények
Legyen Ön az első, aki véleményt ír!
Véleményt írok!
Letöltések


Declaration of Conformity UKCA
Declaration of Conformity CE
Instruction manual
